Switch Matrices
MPG Solutions® offers a variety of customizable Switch Matrices designed specifically for military & defense applications. Supplying the industries with ruggedized systems for 70+ years.
Overview
- Designed and developed for commercial and military environments, our RF switch matrix solutions offer a variety of high density, RF Switching (Tx and Rx) configurations including low/high frequency, low/high power, narrowband and broadband solutions from DC to 50GHz. Units can be equipped with active or passive components in addition to any switches.
Benefits
Reliably routing the input signal to any output port, Switch Matrices are applicable for complex applications where multiple I/O signals increase switching complexity.
- Situations where high-density RF switching (transmitting and receiving) for narrowband, low frequency and low power applications are required
- Support for low power and high-density signal routing both on the transmitter (Fan-Out) and receiver (Fan-In) side
Problems Solved
Reliably routing the input signal to any output port, Switch Matrices are applicable for complex applications where multiple I/O signals increase switching complexity.
- Situations where high-density RF switching (transmitting and receiving) for narrowband, low frequency and low power applications are required
- Support for low power and high-density signal routing both on the transmitter (Fan-Out) and receiver (Fan-In) side
DOWNLOAD MPG'S SATCOM GROUND STATION WHITE PAPER
Markets & Applications
MPG Sales
Connecting & Protecting People®
MPG Solutions® provides expert support throughout all of the phases in our customer experience, from quoting the perfect solution to continued post-delivery support and extended warranty coverage. Let's take on your latest design challenge together.
Benefits
MODULAR
SWaP
CUSTOM DESIGN
Technical Questions?
Our team is composed of highly-technical engineers empowered to quickly assist you in identifying a high-performance RF/microwave solutions. Contact our engineers to see how we can solve your mission-critical challenges.
Special Processes & Technologies
- Certified to AS9100 quality management system
- Compliance with the following soldering and workmanship standards:
- IPC J-STD-001
- IPC J-STD-001S
- IPC-A-610 Class 3
- NASA-STD 8739.3
- IPC J-STD-001
- In house environment testing facility, including:
- Vibration and shock
- Temperature chambers
- Thermal vacuum chambers
- Thermal shock chambers
- High power radio frequency
- High power radio frequency
- Network analyzers up to 65 GHz
- Passive Inter-Modulation (PIM)
- Multipaction
- Vibration and shock
- Two Class 7 Clean Rooms to ISO 14644-1
- Class 5 flow bench assemblies
- Dow-Key’s inspection capabilities include:
- Optical coordinate-measuring machine
- Coordinate-measuring machine
- X-Ray florescence analyzer
- Optical coordinate-measuring machine
- Calibration of test and measurement equipment through qualified outside sources
